Specificatii Tehnice
Factor de putere
>0,4
Forma constructiva
carcasa pentru aparatura modulara
Marime fuzibil
Internal protective fuse: T 3.15 A;External fuse on AC line: MCB: C-3.15 A / Fuse: T 3.15 A
Tensiune intrare AC
90-264 V
Dimensiuni externe
41 x 100 x 92 mm
Redundant parallel connection
Possible with external ORing diode
Materialul carcasei
Plastic;Clasa V0 conform cu UL-94
Frecventa
47-63 Hz
Descriere electrica CAD
/, 2,5A (50°C)
Versiune
sursa alimentare in comutatie
Conexiune
1,5mmp / 1,5mmp
PROMO CODE CH
4652-0057-52
Current consumption
1.6 A (115VAC) / 0.9 A (230VAC)
Terminale externe CAD
1
Hold up time
20 ms (115VAC) / 50 ms (230VAC)
Incarcare maxima
2,5 A
Curent de scurtcircuit
20 A for 100 ms
LxBxH mm
41x92x100
Isolation
Input/output isolation: 3 kV AC / 60 s;Input/ground insulation: 2 kV AC / 60 s;Output/ground insulation: 0.5 kV AC / 60 s
Toleranta tensiune
4.0 A
Temperatura maxima a mediului ambiant
70 °C
PROMO CODE GER INDUSTRY
4652-00031-96
PREG
2320
Technical data
##
Tensiune DC la iesire
24 V
grad de protectie
IP20
Grad de poluare
2
Masa neta
0,28 kg/m
Curent la pornire
30 A (115VAC) / 60 A (230VAC)
COD COMANDA
LPC12402
Efficiency (depending on input voltage)
86% (115VAC) / 88% (230VAC)
COD PROMO
4652-0037-90
Unitate de ambalare
1 m.
Tensiune de intrare DC
127-370 V
Simbol CAD
T
Tensiunea de alimentare
24 DC V
Masa aprox.
0,28 kg/km
Fabricant
Schrack
Contacte
dry contact, max. 1 A
Functie
surse alimentare
Categoria de supratensiune
3
Intrare
##
-
Sommeroffer
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
disipare
13,00 W
Temperatura minima a mediului ambiant
-25 °C
Status LEDs
LED "DC OK"
Ripple at nominal ratings
150 mVpp
Putere
60 W
Power loss (depending on input voltage)
10 W (115VAC) / 8 W (230VAC)
Tensiune nominala
120-230VAC
Adancime montaj
8 mm
Standard
EN 62368-1;EN 55032;EN 55035;EN 61000-3-2;EN 61000-3-3;EN 61000-4-2;EN 61000-4-3;EN 61000-4-4;EN 61000-4-5;EN 61000-4-6;EN 61000-4-8;EN 61000-4-11
Temperatura de functionare
-20°C…+70°C (derating -1,6 W/°C >55°C)
Iesire
##
| Lungime | 41 mm |
| Latime | 92 mm |
| Inaltime | 100 mm |
| Greutate | 0.28 kg |
