Specificatii Tehnice
PREG
2330
Carcasa
##
Masa neta
0,32 kg/m
PROMO CODE CH
6856-0030-00
Temperatura maxima a mediului ambiant
60 °C
Terminale externe CAD
1
Accesorii optionale
MGX20006--;MGX20306--;MGX20406--
Curent primar
400 A
Clasa de precizie
##
COD COMANDA
MG956040-A
Descriere electrica CAD
400/5A, 50x20mm
COD PROMO
6856-0018-11
Intended use
for copper bars up to 50 x 30mm;for copper bars up to 60 x 10mm
Unitate de ambalare
1 m.
Winding secondary side
Screw terminals M4;Faston 4,8x0,8mm
Fabricant
Schrack
Nota
The converter is not allowed to be operated with open secondary side, because this leads to a dangerous overvoltage at the secondary side and overheating of the converter!!! (EN60044-1/A2);Therefore, when disconnecting the measuring device, meter or power analyzer, short-circuit the secondary side.
Temperatura minima a mediului ambiant
-25 °C
LxBxH mm
61x70x95
grad de protectie
IP00 terminals;IP20 with terminal cover
Simbol CAD
P
Masa g
500
disipare
16,00 W
Rated current primary side Ipr
400 A
Rated frequency
50 Hz
Ardere
Class 1 (4VA);Class 3 (6VA)
Standard produs
EN 61869-2
Decupaj mm
50x30;60x10 mm
Bare colectoare maxim
60x10
DECUPAJ mm
50x30
Montaj
by fixing screws on the busbar
Tip
Prin transformator de curent
Materialul carcasei
Policarbonat, cu autostingere
Conexiune
##
Rated current secondary side Isr
5A
Clasa
1
PROMO CODE GER INDUSTRY
6856-00015-64
| Lungime | 60.5 mm |
| Latime | 70 mm |
| Inaltime | 95 mm |
| Greutate | 0.32 kg |
