Surge Arrester f 60mm System 3+1 AX+LF TT/TN-S, Class1+2(BC)
Cod produs: IS254131--
Marca: SCHRACK TECHNIK
Pret cu TVA: 2774.25 Lei / buc.
|
|
|
|
|
|
Comanda instant - Surge Arrester f 60mm System 3+1 AX+LF TT/TN-S, Class1+2(BC)
|
Surge Arrester f 60mm System 3+1 AX+LF TT/TN-S, Class1+2(BC)
|
|
Specificatii Tehnice PREG 1400 Specific Energy 39/625 kJ/Ω Timp de raspuns <25/<100 ns Charge 6,25/25 As TOV SafeFail 120min (L-N) 442 V disipare 0,16 W Leakage current free Yes Impuls de curent 12,50/50 kA Clasa de protectie TI+TII/B+C PU 20 Curent descarcare nominal 20/80 kA Tensiune nominala 240VAC Simbol CAD F Unitate de ambalare 1 m. TOV Withstand 200ms (N-PE) 1200 V Capacitate de comutare a curentului de urmarire 100 A Fabricant Schrack Curent descarcat maxim 65/100 kA Temperatura maxima a mediului ambiant 85 °C Masa neta 0,61 kg/m COD COMANDA IS254131 Nivel de protectie 1,5 kV TOV Withstand 5s (L-N) 442 V LxBxH mm 245x36x123 Overcurrent Protection (max) 315 A gG Temperatura minima a mediului ambiant -40 °C Rezistenta la scurtcircuit 25 kA Circuit 3+1 Contact semnalizare da Tensiune nominala maxima AC 300 VAC | Lungime | 244.5 mm | | Latime | 36 mm | | Inaltime | 123.3 mm | | Greutate | 0.61 kg |
|
|
|
|
|
