Specificatii Tehnice
PREG
2330
Carcasa
##
Bare colectoare maxim
60x30
Winding secondary side
Screw terminals M4
Temperatura maxima a mediului ambiant
60 °C
LxIxA mm
90x90x94
Masa neta
0,75 kg/m
Terminale externe CAD
1
Accesorii optionale
MGX20006--;MGX20306--;MGX20406--
Masa g
750
HxBxT mm
90x90x94
Clasa de precizie
##
Standard produs
EN 61869-2;BS3938;BS7626
PU
3
Clasa
0,5
COD COMANDA
MG957080-A
Unitate de ambalare
1 m.
Ardere
Class 0.5 (12VA);Class 1 (15VA);Class 3 (20VA)
PROMO CODE CH
6887-0031-98
DECUPAJ mm
65x32
Materialul carcasei
Policarbonat, cu autostingere;Clasa V0 conform cu UL-94
PROMO CODE GER INDUSTRY
6887-00018-49
Fabricant
Schrack
Intended use
for copper bars up to 65 x 32mm
Nota
The converter is not allowed to be operated with open secondary side, because this leads to a dangerous overvoltage at the secondary side and overheating of the converter!!! (EN60044-1/A2);Therefore, when disconnecting the measuring device, meter or power analyzer, short-circuit the secondary side.
Temperatura minima a mediului ambiant
-25 °C
grad de protectie
IP00 terminals;IP20 with terminal cover
Decupaj mm
65x32 mm
Simbol CAD
P
Curent primar
800 A
Rated frequency
50 Hz
COD PROMO
6887-0019-29
Specifications
##
Descriere electrica CAD
800/5A, 60x20mm
Montaj
by fixing screws on the busbar
Tip
Prin transformator de curent
Conexiune
##
Rated current primary side Ipr
800 A
disipare
20,00 W
Rated current secondary side Isr
5A
| Lungime | 94 mm |
| Latime | 90 mm |
| Inaltime | 90 mm |
| Greutate | 0.75 kg |
