Specificatii Tehnice
PREG
2330
Carcasa
##
Descriere electrica CAD
2000/5A, 64x20mm
Bare colectoare maxim
60x30
Winding secondary side
Screw terminals M4
Temperatura maxima a mediului ambiant
60 °C
LxIxA mm
90x90x94
Masa neta
0,75 kg/m
Terminale externe CAD
1
Accesorii optionale
MGX20006--;MGX20306--;MGX20406--
Masa g
750
HxBxT mm
90x90x94
Clasa de precizie
##
Standard produs
EN 61869-2;BS3938;BS7626
PU
3
Curent primar
2000 A
Clasa
0,5
Unitate de ambalare
1 m.
DECUPAJ mm
65x32
Materialul carcasei
Policarbonat, cu autostingere;Clasa V0 conform cu UL-94
Fabricant
Schrack
COD COMANDA
MG957200-A
Intended use
for copper bars up to 65 x 32mm
Nota
The converter is not allowed to be operated with open secondary side, because this leads to a dangerous overvoltage at the secondary side and overheating of the converter!!! (EN60044-1/A2);Therefore, when disconnecting the measuring device, meter or power analyzer, short-circuit the secondary side.
Ardere
Class 0.5 (20VA);Class 1 (25VA);Class 3 (30VA)
PROMO CODE CH
6022-0042-52
Temperatura minima a mediului ambiant
-25 °C
grad de protectie
IP00 terminals;IP20 with terminal cover
PROMO CODE GER INDUSTRY
6022-00022-54
Decupaj mm
65x32 mm
Simbol CAD
P
Rated frequency
50 Hz
Specifications
##
Montaj
by fixing screws on the busbar
Tip
Prin transformator de curent
COD PROMO
6022-0025-63
Conexiune
##
disipare
20,00 W
Rated current secondary side Isr
5A
Rated current primary side Ipr
2000 A
| Lungime | 94 mm |
| Latime | 90 mm |
| Inaltime | 90 mm |
| Greutate | 0.75 kg |
