Specificatii Tehnice
Stabilitate la impuls de tensiune Uimp
4kV
COD COMANDA
AR876130
PROMO CODE GER INDUSTRY
6352-00330-86
Terminal type
Double Mouth Lift Clamp with Back clamps Protection
Tensiune nominala
230/400V AC 4-polig
Max. allowed back-up fuse against thermal overload
63A: 40A gG
Simbol CAD
Q
Insulation voltage
500 V
Rated frequency
50/ 60 Hz
Standard produs
EN 61008-1:2012 + A1:2014 + A2:2014 + A11:2015 + A12:2017;EN 61008-2-1:1994 + A11:1998;EN 62423:2012
Temperatura maxima a mediului ambiant
60 °C
Curent nominal
63 A
Masa neta
0,37 kg/m
Max. permissible back-up fuse against short circuit
63 A gG
Terminal cross section
2,5 - 35 mm²
LxBxH mm
50x72x84
PROMO CODE GER
6352-0388-78
Capacitate de rupere nominala
10 kA
grad de protectie
IP20
Grad de poluare
2
Afisaj
rosu daca e declansat
Cuplu maxim
2,50 Nm
PREG
1380
PROMO CODE CH
6352-0349-83
Unitate de ambalare
1 m.
Descriere electrica CAD
63A/4/300mA
PU
45
Serie
AMPARO
COD PROMO
6352-0167-12
Tensiune dielectrica de test la frecventa industriala
2500 V
Cuplu
2.5 Nm
Temperatura ambianta pentru montaj deschis
-25°C bis +40°C °C
Standard
EN 61008-1;IEC 61008-1;EN 62423;IEC 62423
Non-tripping residual current
≤0,5 IΔn
Fabricant
Schrack
Rated sensitivity IΔn
300 mA
Rezistenta la scurtcircuit
10 kA
Durata de viata electrica
2000 Operations
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
Temperatura minima a mediului ambiant
-25 °C
Curent nominal
63 A
Capacitate nominala de rupere Im
630 A
Categorie produs
tip B (sensibil la curent continuu si pulsatoriu)
Tip
fara temporizare
Valoare curent de defect
300 mA
disipare
31,97 W
Poli
N+3
Accesorii optionale
AM900003--;BSA90157--;BSA90158--;BSA90159--
Descriere de baza
Intreruptor diferential
Conductor masiv
2.5 - 35 mm²
Material conductor
Copper
Timp de declansare instantaneu
IΔn: ≤300ms;2 x IΔn: ≤150ms;≥5 x IΔn: ≤40ms
Durata de viata mecanica
10000 Operations
| Lungime | 49.5 mm |
| Latime | 72 mm |
| Inaltime | 84 mm |
| Greutate | 0.37 kg |
