Specificatii Tehnice
Standard
EN 61008-1;IEC 61008-1
Max. allowed back-up fuse against thermal overload
63A: 40A gG
Simbol CAD
Q
Masa neta
0,21 kg/m
Insulation voltage
500 V
Rated frequency
50/ 60 Hz
Temperatura maxima a mediului ambiant
60 °C
PROMO CODE CH
2784-0031-22
PROMO CODE GER INDUSTRY
2784-00017-57
Terminale externe CAD
1
Curent nominal
63 A
Categorie produs
A (sensibil la curent alternativ si pulsatoriu)
Max. permissible back-up fuse against short circuit
63 A gG
Terminal cross section
1,5 - 25 mm²
Tip
S (selectiv)
Stabilitate la impuls de tensiune Uimp
6kV
Descriere electrica CAD
63A/2P/300mA/S
Capacitate de rupere nominala
10 kA
grad de protectie
IP20
Grad de poluare
2
Afisaj
rosu daca e declansat
Cuplu maxim
2,50 Nm
Conductor masiv
1,5 - 25 mm²
PREG
1380
LxBxH mm
50x36x84
Unitate de ambalare
1 m.
Serie
AMPARO
Tensiune dielectrica de test la frecventa industriala
2500 V
Cuplu
2.5 Nm
disipare
9,40 W
Non-tripping residual current
≤0,5 IΔn
PU
90
Terminal type
Lift clamp cable / pin busbar
Fabricant
Schrack
Rated sensitivity IΔn
300 mA
Rezistenta la scurtcircuit
10 kA
Certificates
VDE for type A in 2 pole version
Durata de viata electrica
2000 Operations
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
Accesorii optionale
BSB90111ME;BSB90112ME;BSA90161--;BSA90154--;BSA90162--
Temperatura minima a mediului ambiant
-25 °C
Curent nominal
63 A
Capacitate nominala de rupere Im
630 A
COD COMANDA
AR066230
COD PROMO
2784-0014-91
Valoare curent de defect
300 mA
Poli
N+1
Standard produs
EN 61008-1:2012 + A1:2014 + A2:2014 + A11:2015 + A12:2017;EN 61008-2-1:1994 + A11:1998;IEC 61008-1;IEC 61008-2-1;AS/NZS 61008.1
Descriere de baza
Intreruptor diferential
Durata de viata mecanica
2000 Operations
Material conductor
Copper
Tensiune nominala
230V-AC
Temperatura ambianta pentru montaj deschis
-25°C bis +55 °C
Timp de declansare S
IΔn: ≥130ms si ≤500ms;2 x IΔn: ≥60ms si ≤200ms;5 x IΔn: ≥50ms si ≤150ms;≥5 x IΔn: ≥40ms si ≤150ms
| Lungime | 49.5 mm |
| Latime | 36 mm |
| Inaltime | 84 mm |
| Greutate | 0.21 kg |
