Specificatii Tehnice
Curent nominal
40 A
Stabilitate la impuls de tensiune Uimp
4kV
Descriere electrica CAD
${nennstrom}/${pole}/${nennfehlerstrom},B
Terminal type
Double Mouth Lift Clamp with Back clamps Protection
Tensiune nominala
230/400V AC 4-polig
Simbol CAD
Q
PROMO CODE CH
6758-0349-83
Insulation voltage
500 V
Rated frequency
50/ 60 Hz
Standard produs
EN 61008-1:2012 + A1:2014 + A2:2014 + A11:2015 + A12:2017;EN 61008-2-1:1994 + A11:1998;EN 62423:2012
Temperatura maxima a mediului ambiant
60 °C
Valoare curent de defect
30 mA
disipare
12,88 W
COD COMANDA
AR874103
Masa neta
0,37 kg/m
Max. permissible back-up fuse against short circuit
63 A gG
Terminal cross section
2,5 - 35 mm²
LxBxH mm
50x72x84
Capacitate de rupere nominala
10 kA
grad de protectie
IP20
Grad de poluare
2
Afisaj
rosu daca e declansat
Cuplu maxim
2,50 Nm
PREG
1380
Unitate de ambalare
1 m.
PU
45
Serie
AMPARO
Tensiune dielectrica de test la frecventa industriala
2500 V
Cuplu
2.5 Nm
Temperatura ambianta pentru montaj deschis
-25°C bis +40°C °C
Standard
EN 61008-1;IEC 61008-1;EN 62423;IEC 62423
Non-tripping residual current
≤0,5 IΔn
PROMO CODE GER
6758-0347-50
COD PROMO
6758-0167-12
Rated sensitivity IΔn
30 mA
Fabricant
Schrack
Rezistenta la scurtcircuit
10 kA
Durata de viata electrica
2000 Operations
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
Temperatura minima a mediului ambiant
-25 °C
Curent nominal
40 A
Categorie produs
tip B (sensibil la curent continuu si pulsatoriu)
Capacitate nominala de rupere Im
500 A
Tip
fara temporizare
Poli
N+3
Accesorii optionale
AM900003--;BSA90157--;BSA90158--;BSA90159--
Descriere de baza
Intreruptor diferential
Conductor masiv
2.5 - 35 mm²
Max. allowed back-up fuse against thermal overload
40A: 25A gG
Material conductor
Copper
Timp de declansare instantaneu
IΔn: ≤300ms;2 x IΔn: ≤150ms;≥5 x IΔn: ≤40ms
Durata de viata mecanica
10000 Operations
PROMO CODE GER INDUSTRY
6758-00295-74
| Lungime | 49.5 mm |
| Latime | 72 mm |
| Inaltime | 84 mm |
| Greutate | 0.37 kg |
