Specificatii Tehnice
PREG
2330
Putere reactiva (toleranta)
Clasa 1
Temperatura de functionare
-5°C to +55°C
Carcasa
##
disipare
6,00 W
Rama frontala
96 x 96mm mm
Rated frequency
50Hz - 60Hz (automatische Wahl) Hz
Precizie
##
Current (tolerance)
Class 0.5
Voltage (three-phase network)
80 ... 500 V (phase-phase)
Valori afisate
Pagini de display personalizate;Conexiuni (tip de retea);Putere medie / temporizare curenta;Start masura (contor de ore de functionare);Punct de masura RS485;Raport de transformare de curent;iesire in impulsuri
Immunity test
according to EN 61326-1 , IEC 61326-1
Compatibilitate electromagnetica
##
Conexiune
Clema cu surub
Buton
4 front keys, access protected by password
Conexiune (tensiune)
Conductor (masiv) min. 0,05mmp / max. 4mmp;Conductor (flexibil) min. 0,05mmp / max. 2,5mmp
Tipul carcasei
Pentru montaj pe panou (decupaj 92 x 92 mm)
Auto consum (circuit de tensiune)
≤ 0.2VA (faza - nul)
Overload (short-time)
20 In / 0.5 seconds
Temperatura maxima a mediului ambiant
70 °C
Insulation voltage
300V (phase - neutral)
Mains type
Alternating current network and 4-wire three-phase network
Voltage (tolerance)
Class 0.5
Tip
panou frontal
Test emisii
conform cu EN 61326-1 class B, IEC 61326-1 class B
Grad de poluare
2
Voltage (alternating current network)
50 … 290 V
Functie
Analizor de retea
Overload (continuous)
1.2 In
Conditii de lucru
##
Auxiliary voltage
##
Power (tolerance)
Class 1
Nominal current (input)
5A - nur Stromwandleranschluss
Unitate de ambalare
1 m.
Reference temperature
23 ± 2 °C
COD COMANDA
MGF37900
Indicatie afisaj
4 linii / 4 digiti
Marime
96x96mm
Frecventa de lucru
45 … 65 Hz
Gama de temperatura - Transport/Depozitare
-25 to +70 °C
Afisaj
Ecran LCD cu iluminare de fundal
Installation category
III
Test circuit
all circuits and ground
Fabricant
Schrack
COD PROMO
1387-0138-67
Frecventa (toleranta)
± 0,1 Hz
alimentare
din circuitul de masura (Faza L1 - N)
Intrare
##
Afisaj
##
Adancime
62 mm
Temperatura minima a mediului ambiant
-25 °C
grad de protectie
IP54 (front), IP20 (connections)
Masa neta
0,29 kg/m
Isolation test voltage
3 kV R.M.S. 50 Hz/1min
Real energy (tolerance)
Class 1
PROMO CODE CH
1387-0213-88
Conexiune (curent)
Conductor (masiv) min. 0,05mmp / max. 4mmp;Conductor (flexibil) min. 0,05mmp / max. 2,5mmp
PROMO CODE GER INDUSTRY
1387-00129-90
Harmonic content
up to the 40th harmonic
Materialul carcasei
Policarbonat, cu autostingere
Programming
##
LxBxH mm
74x96x96
Auto consum (circuit de curent)
≤ 0.4VA (pe faza la max 6A)
| Lungime | 74 mm |
| Latime | 96 mm |
| Inaltime | 96 mm |
| Greutate | 0.29 kg |
