POWERTEC PF 25kA +H+S, T1-275, 1+0, pluggable, integr. fuse
Cod produs: IS010127--
Marca: SCHRACK TECHNIK
Pret cu TVA: 1343.26 Lei / buc.
|
|
|
|
|
|
Comanda instant - POWERTEC PF 25kA +H+S, T1-275, 1+0, pluggable, integr. fuse
|
POWERTEC PF 25kA +H+S, T1-275, 1+0, pluggable, integr. fuse
|
|
Specificatii Tehnice PREG 1400 TOV SafeFail 120min (L-N) 442 V Timp de raspuns <100 ns Leakage current free Yes Open Circuit Voltage of Combination Wave Generator (1,2/50μs) 6 kV Impuls de curent 25 kA Tensiune nominala 240VAC Short Circuit Current of Combination Wave Generator (8/20μs) 3 kA Circuit 1+0 Simbol CAD F Charge 12,50 As Curent descarcat maxim 65 kA Unitate de ambalare 1 m. Capacitate de comutare a curentului de urmarire 100 A COD PROMO 4519-0162-96 Curent descarcare nominal 25 kA Fabricant Schrack Masa neta 0,33 kg/m Nivel de protectie 1500 kV Temperatura maxima a mediului ambiant 85 °C Module 2 PU 7 Temperatura minima a mediului ambiant -40 °C Rezistenta la scurtcircuit 100 Tensiune nominala maxima AC 275 VAC COD COMANDA IS010127 Contact semnalizare da Overcurrent Protection (max) nicht notwendig A gG Specific Energy 156,20 kJ/Ω LxBxH mm 86x36x105 | Lungime | 86 mm | | Latime | 36 mm | | Inaltime | 105 mm | | Greutate | 0.33 kg |
|
|
|
|
|
