POWERTEC PF 25kA +H, T1 275, 3+0, pluggable, integr. fuse
Cod produs: IS010130--
Marca: SCHRACK TECHNIK
Pret cu TVA: 4086.88 Lei / buc.
|
|
|
|
|
|
Comanda instant - POWERTEC PF 25kA +H, T1 275, 3+0, pluggable, integr. fuse
|
POWERTEC PF 25kA +H, T1 275, 3+0, pluggable, integr. fuse
|
|
Specificatii Tehnice PREG 1400 Nivel de protectie 1900 kV Masa neta 0,97 kg/m TOV SafeFail 120min (L-N) 442 V Timp de raspuns <100 ns Module 6 Open Circuit Voltage of Combination Wave Generator (1,2/50μs) 6 kV COD COMANDA IS010130 Impuls de curent 25 kA disipare 7,20 W Tensiune nominala 240VAC PU 3 Short Circuit Current of Combination Wave Generator (8/20μs) 3 kA Simbol CAD F Charge 12,50 As Curent descarcat maxim 65 kA Unitate de ambalare 1 m. Capacitate de comutare a curentului de urmarire 100 A Curent descarcare nominal 25 kA Temperatura maxima a mediului ambiant 85 °C Circuit 3+0 LxBxH mm 109x86x90 Temperatura minima a mediului ambiant -40 °C Rezistenta la scurtcircuit 100 Tensiune nominala maxima AC 275 VAC Contact semnalizare da Overcurrent Protection (max) nicht notwendig A gG Specific Energy 156,20 kJ/Ω | Lungime | 109 mm | | Latime | 86 mm | | Inaltime | 90 mm | | Greutate | 0.97 kg |
|
|
|
|
|
