Specificatii Tehnice
Terminal type
Double Mouth Lift Clamp with Back clamps Protection
Calibration-Temperature
30 °C
Accesorii optionale
AM900099--;BSB90125-A;AM900008--;AM900006--;AM900005--
Rated frequency
50/ 60 Hz
Terminale externe CAD
1
Tensiune nominala
230/400 - 240/415V
Poli
4
Temperatura maxima a mediului ambiant
70 °C
Temperatura ambianta pentru montaj deschis
-5°C bis +40 °C
Masa neta
0,41 kg/m
grad de protectie
IP20
Grad de poluare
2
COD COMANDA
AM617420
disipare
16,10 W
Versiune
Intreruptor automat AC
PU
3
Curent nominal
20 A
Terminal cross section
1-25 mm²
Cuplu maxim
2,50 Nm
PREG
1380
Simbol CAD
F
Clamp size for busbar
10 mm²
Categorie produs
AM6
LxBxH mm
86x72x77
Unitate de ambalare
1 m.
Serie
AMPARO
Cuplu
2.5 Nm
Capacitate de rupere nominala
6 kA
Rezistenta la scurtcircuit
6 kA (IEC/EN 60898)
Fabricant
Schrack
Temperatura minima a mediului ambiant
-35 °C
Caracteristica declansare
C
Tensiunea de test
2000 V
Poztie de montaj
Oricare
Standard
EN 60898-1;IEC 60898-1
Conexiune
ambele parti
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
Internal resistance
20A: 3.832mΩ
COD PROMO
1984-0009-20
Descriere de baza
Intreruptor automat modular
Energy limiting class
3
Selectivitate
IS503046--; IS503750--; IS503850--; IS504038--; IS504718-A; IS5047PL50; M142201---; IS503041--; IS503042--; IS503563--; IS503705--; IS503763--; IS503863--; IS504039--; IS504719-A; IS5047PL63; IS504700-A; IS504703-A; IS504704-A; IS504705--; IS504706--; IS504707--; IS504708--; IS504709--; M142202---
PROMO CODE CH
1984-0018-70
Durata de viata electrica
4000 Operations
Gama de temperatura - Functionare
-35 to +70 °C
Standard produs
EN 60898-1:2019;IEC 60898-1
Material conductor
Copper
Descriere electrica CAD
${kennlinie}/${nennstrom}/${pole}
Curent nominal
20 A
Durata de viata mecanica
20000 Operations
Stabilitate la impuls de tensiune Uimp
4kV
Conductor masiv
1-25 mm²
| Lungime | 86 mm |
| Latime | 72 mm |
| Inaltime | 77 mm |
| Greutate | 0.41 kg |
