Specificatii Tehnice
Terminal type
Double Mouth Lift Clamp with Back clamps Protection
Calibration-Temperature
30 °C
Rated frequency
50/ 60 Hz
Terminale externe CAD
1
Curent nominal
63 A
Tensiune nominala
230/400 - 240/415V
Temperatura maxima a mediului ambiant
70 °C
Temperatura ambianta pentru montaj deschis
-5°C bis +40 °C
grad de protectie
IP20
Grad de poluare
2
Versiune
Intreruptor automat AC
PROMO CODE GER INDUSTRY
1166-00002-37
Terminal cross section
1-25 mm²
Cuplu maxim
2,50 Nm
disipare
5,75 W
Poli
1
Masa neta
0,11 kg/m
PREG
1380
Simbol CAD
F
Clamp size for busbar
10 mm²
PROMO CODE CH
1166-0005-23
Categorie produs
AM6
Unitate de ambalare
1 m.
Serie
AMPARO
COD COMANDA
AM617163
Cuplu
2.5 Nm
COD PROMO
1166-0002-56
Capacitate de rupere nominala
6 kA
PROMO CODE GER
1166-0002-31
Rezistenta la scurtcircuit
6 kA (IEC/EN 60898)
Internal resistance
63A: 1.055mΩ
Fabricant
Schrack
Temperatura minima a mediului ambiant
-35 °C
Caracteristica declansare
C
Tensiunea de test
2000 V
Poztie de montaj
Oricare
Standard
EN 60898-1;IEC 60898-1
Conexiune
ambele parti
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
PU
12
Curent nominal
63 A
Descriere de baza
Intreruptor automat modular
LxBxH mm
86x18x77
Energy limiting class
3
Accesorii optionale
AM900099--;BSB90113-A;BSB90114-A;BSB90155-A;AM900008--;AM900006--;AM900005--
Durata de viata electrica
4000 Operations
Gama de temperatura - Functionare
-35 to +70 °C
Standard produs
EN 60898-1:2019;IEC 60898-1
Material conductor
Copper
Descriere electrica CAD
${kennlinie}/${nennstrom}/${pole}
Durata de viata mecanica
20000 Operations
Stabilitate la impuls de tensiune Uimp
4kV
Conductor masiv
1-25 mm²
| Lungime | 86 mm |
| Latime | 18 mm |
| Inaltime | 77 mm |
| Greutate | 0.11 kg |
