Specificatii Tehnice
Internal resistance
40A: 1.660mΩ
Terminal type
Double Mouth Lift Clamp with Back clamps Protection
Calibration-Temperature
30 °C
Rated frequency
50/ 60 Hz
PROMO CODE CH
1326-0008-17
Terminale externe CAD
1
Accesorii optionale
BSA90139--;BSB00111-A;BSB00112--;BSA90153--;BSA90154--;AM900099--;AM900008--;AM900006--;AM900005--
Tensiune nominala
230/400 - 240/415V
COD PROMO
1326-0004-02
Temperatura maxima a mediului ambiant
70 °C
Temperatura ambianta pentru montaj deschis
-5°C bis +40 °C
grad de protectie
IP20
Grad de poluare
2
Versiune
Intreruptor automat AC
Terminal cross section
1-25 mm²
Cuplu maxim
2,50 Nm
disipare
5,75 W
PREG
1380
Simbol CAD
F
Categorie produs
AM6
Unitate de ambalare
1 m.
Serie
AMPARO
Cuplu
2.5 Nm
Capacitate de rupere nominala
6 kA
Rezistenta la scurtcircuit
6 kA (IEC/EN 60898)
Fabricant
Schrack
Temperatura minima a mediului ambiant
-35 °C
Caracteristica declansare
C
PROMO CODE GER INDUSTRY
1326-00003-92
Tensiunea de test
2000 V
Poztie de montaj
Oricare
Standard
EN 60898-1;IEC 60898-1
Conexiune
ambele parti
COD COMANDA
AM617640
LxBxH mm
86x36x77
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
Descriere de baza
Intreruptor automat modular
Energy limiting class
3
Curent nominal
40 A
PU
6
Durata de viata electrica
4000 Operations
Masa neta
0,19 kg/m
Poli
N+1
Gama de temperatura - Functionare
-35 to +70 °C
Standard produs
EN 60898-1:2019;IEC 60898-1
Material conductor
Copper
Descriere electrica CAD
${kennlinie}/${nennstrom}/${pole}
Curent nominal
40 A
Durata de viata mecanica
20000 Operations
Stabilitate la impuls de tensiune Uimp
4kV
Conductor masiv
1-25 mm²
| Lungime | 86 mm |
| Latime | 36 mm |
| Inaltime | 77 mm |
| Greutate | 0.19 kg |
