Specificatii Tehnice
Terminal type
Double Mouth Lift Clamp with Back clamps Protection
Calibration-Temperature
30 °C
Rated frequency
50/ 60 Hz
Terminale externe CAD
1
Accesorii optionale
BSA90139--;BSB00111-A;BSB00112--;BSA90153--;BSA90154--;AM900099--;AM900008--;AM900006--;AM900005--
Tensiune nominala
230/400 - 240/415V
PROMO CODE GER INDUSTRY
1272-00003-80
Temperatura maxima a mediului ambiant
70 °C
Temperatura ambianta pentru montaj deschis
-5°C bis +40 °C
COD COMANDA
AM617613
grad de protectie
IP20
Grad de poluare
2
disipare
4,03 W
Versiune
Intreruptor automat AC
Terminal cross section
1-25 mm²
Cuplu maxim
2,50 Nm
PREG
1380
Simbol CAD
F
Internal resistance
13A: 7.880mΩ
Categorie produs
AM6
Unitate de ambalare
1 m.
Serie
AMPARO
Cuplu
2.5 Nm
Capacitate de rupere nominala
6 kA
Curent nominal
13 A
Rezistenta la scurtcircuit
6 kA (IEC/EN 60898)
Fabricant
Schrack
Temperatura minima a mediului ambiant
-35 °C
Caracteristica declansare
C
Tensiunea de test
2000 V
Poztie de montaj
Oricare
Standard
EN 60898-1;IEC 60898-1
Conexiune
ambele parti
LxBxH mm
86x36x77
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
PROMO CODE CH
1272-0008-17
Descriere de baza
Intreruptor automat modular
Energy limiting class
3
PU
6
Durata de viata electrica
4000 Operations
Masa neta
0,19 kg/m
Poli
N+1
Gama de temperatura - Functionare
-35 to +70 °C
Standard produs
EN 60898-1:2019;IEC 60898-1
Material conductor
Copper
Curent nominal
13 A
Descriere electrica CAD
${kennlinie}/${nennstrom}/${pole}
COD PROMO
1272-0004-02
Durata de viata mecanica
20000 Operations
Stabilitate la impuls de tensiune Uimp
4kV
Conductor masiv
1-25 mm²
| Lungime | 86 mm |
| Latime | 36 mm |
| Inaltime | 77 mm |
| Greutate | 0.19 kg |
