Specificatii Tehnice
Terminal cross section
1-16 mm²
Rezistenta la scurtcircuit
4,5 kA (IEC/EN 60898)
Calibration-Temperature
30 °C
COD COMANDA
AM417513
Insulation voltage
500 V
Rated frequency
50/ 60 Hz
Terminale externe CAD
1
Versiune
intreruptor modular, 1+N, 1 modul
Temperatura maxima a mediului ambiant
70 °C
grad de protectie
IP20
Grad de poluare
2
PU
15
Accesorii optionale
BSA90121--;BSA90120--;BSA90122--;BSA90169--;BSA90164--;BSA90167--;BSA90170--;AM900099--;AM900008--;AM900006--;AM900005--
Capacitate de rupere nominala
4,50 kA
Masa neta
0,11 kg/m
PREG
1380
Simbol CAD
F
Categorie produs
1+N la 1UH
Internal resistance
13A: 7.880mΩ
Unitate de ambalare
1 m.
Tensiune nominala
230/240V
Serie
AMPARO
Curent nominal
13 A
Cuplu
2 Nm
Terminal type
Pin busbar
Fabricant
Schrack
Caracteristica declansare
C
Tensiunea de test
2000 V
Poztie de montaj
Oricare
Standard
EN 60898-1;IEC 60898-1
Conexiune
ambele parti
Montaj
On DIN rail according to EN 60715 (35mm) via quick mounting clip
Temperatura minima a mediului ambiant
-25 °C
Descriere de baza
Intreruptor automat modular
Ambient Temperature - nominal Tripping
-5 to +40 °C
LxBxH mm
86x18x77
Energy limiting class
3
Gama de temperatura - Functionare
-25 la +70 °C
disipare
7,00 W
Conductor masiv
1-16 mm²
Cuplu maxim
2 Nm
Poli
N+1
Durata de viata electrica
8000 Operations
Standard produs
EN 60898-1:2019;IEC 60898-1
Material conductor
Copper
Curent nominal
13 A
Descriere electrica CAD
${kennlinie}/${nennstrom}/${pole}
Durata de viata mecanica
20000 Operations
Stabilitate la impuls de tensiune Uimp
4kV
| Lungime | 86 mm |
| Latime | 18 mm |
| Inaltime | 77 mm |
| Greutate | 0.11 kg |
