Specificatii Tehnice
Masa neta
0,02 kg/m
disipare
0,77 W
PU
50
Sectiune maxima, conductor solid
4 mm²
Sistem
cleme cu surub
Unitate de ambalare
50 m.
Serie
TB
Sectiune maxima, conductor flexibil
2,5 mm²
PREG
1670
Sectiune minima, conductor solid
0,2 mm²
Temperatura maxima a mediului ambiant
120 °C
Culoare
Gri inchis
Max. cross section, flexible wire with ferrule
2,5 mm²
COD COMANDA
IP3246903
Accesorii
Installation ground terminal
Min. cross section, flexible wire with ferrule
0,2 mm²
HxBxT mm
63x6x55
LxIxA mm
6x63x55
Descriere de baza
Clema
Accesorii optionale
IP3022263-;IP3022276-;IP3022218-;IP1201442-;IP1201413-;IP1401637-;IP1421659-;IP0800886-;IP196001--;IP196031--;IP196061--;IP196091--;IP196121--;IP196151--;IP196181--;IP196211--;IP196241--;IP196271--;IP196301--;IP196331--;IP196361--;IP196391--;IP196421--;IP196451--;IP196481--;IP10510161;IP10510162;IP10510163;IP10510164;IP10510165;IP10510166;IP10510167;IP10510168;IP10510169;IP1051016H;IP0808710-;IP08087491;IP08087492;IP08087493;IP08087494;IP08087495;IP08087496;IP08087497;IP08087498;IP08087499;IP0808749H;IP3246994-;IP3246910-;IP3246917-;IP3246931-;IP3246938-;IP3246959-;IP0800886-;IP1201413-;IP1201442-;IP1212602-;
Sectiune minima, conductor flexibil
0,2 mm²
Descriere electrica CAD
${querschnitt}
Sectiune
2.5 mm²
Versiune
Protective conductor terminal
Temperatura minima a mediului ambiant
-40 °C
Fabricant
Phoenix Contact
Simbol CAD
X
Curent nominal
15 A
| Lungime | 55.3 mm |
| Latime | 6.2 mm |
| Inaltime | 62.5 mm |
| Greutate | 0.02 kg |
