Specificatii Tehnice
Masa neta
0,02 kg/m
PU
50
Sistem
spring-cage-terminal
COD COMANDA
IP3036039
Unitate de ambalare
50 m.
PREG
1670
Temperatura maxima a mediului ambiant
120 °C
Versiune
Ground-double-level terminal
LxIxA mm
6x84x48
Max. cross section, flexible wire with ferrule
4 mm²
Sectiune maxima, conductor flexibil
4 mm²
Sectiune minima, conductor flexibil
0,08 mm²
Sectiune maxima, conductor solid
6 mm²
Serie
ST
Min. cross section, flexible wire with ferrule
0,14 mm²
Descriere de baza
Clema
Sectiune minima, conductor solid
0,08 mm²
Descriere electrica CAD
${querschnitt}
Culoare
Verde-galben
Accesorii optionale
IP3022263-;IP3022276-;IP3022218-;IP1201442-;IP1201413-;IP1401637-;IP1421659-;IP0800886-;IP196001--;IP196031--;IP196061--;IP196091--;IP196121--;IP196151--;IP196181--;IP196211--;IP196241--;IP196271--;IP196301--;IP196331--;IP196361--;IP196391--;IP196421--;IP196451--;IP196481--;IP10510161;IP10510162;IP10510163;IP10510164;IP10510165;IP10510166;IP10510167;IP10510168;IP10510169;IP1051016H;IP0808710-;IP08087491;IP08087492;IP08087493;IP08087494;IP08087495;IP08087496;IP08087497;IP08087498;IP08087499;IP0808749H;IP3030462-;IP1204517-
Accesorii
Ground-double-level terminal block
Temperatura minima a mediului ambiant
-40 °C
Fabricant
Phoenix Contact
HxBxT mm
84x6x48
Simbol CAD
X
Sectiune
4 mm²
| Lungime | 47.5 mm |
| Latime | 6.2 mm |
| Inaltime | 83.5 mm |
| Greutate | 0.02 kg |
