Specificatii Tehnice
disipare
0,77 W
PU
50
Sectiune maxima, conductor solid
4 mm²
Sistem
spring-cage-terminal
HxBxT mm
75x5x45
Unitate de ambalare
50 m.
PREG
1670
Temperatura maxima a mediului ambiant
120 °C
Accesorii optionale
IP3022263-;IP3022276-;IP3022218-;IP1201442-;IP1201413-;IP1401637-;IP1421659-;IP0800886-;IP196001--;IP196031--;IP196061--;IP196091--;IP196121--;IP196151--;IP196181--;IP196211--;IP196241--;IP196271--;IP196301--;IP196331--;IP196361--;IP196391--;IP196421--;IP196451--;IP196481--;IP10500171;IP10500172;IP10500173;IP10500174;IP10500175;IP10500176;IP10500177;IP10500178;IP10500179;IP1050017H;IP08086711;IP08086712;IP08086713;IP08086714;IP08086715;IP08086716;IP08086717;IP08086718;IP08086719;IP0808671H;IP3209112-;IP3030161-;IP3030174-;IP3030213-;IP0201744-;IP1204517-
Curent nominal
18 A
Accesorii
Installation ground terminal
Culoare
Gri
LxIxA mm
5x75x45
Sectiune minima, conductor flexibil
0,08 mm²
Sectiune maxima, conductor flexibil
2,50 mm²
Serie
ST
Min. cross section, flexible wire with ferrule
0,14 mm²
Descriere de baza
Clema
Masa neta
0,01 kg/m
Sectiune minima, conductor solid
0,08 mm²
COD COMANDA
IP3209141
Descriere electrica CAD
${querschnitt}
Sectiune
2.5 mm²
Versiune
Protective conductor terminal
Max. cross section, flexible wire with ferrule
2,50 mm²
Temperatura minima a mediului ambiant
-40 °C
Fabricant
Phoenix Contact
Simbol CAD
X
| Lungime | 44.5 mm |
| Latime | 5.2 mm |
| Inaltime | 75 mm |
| Greutate | 0.01 kg |
