Specificatii Tehnice
Durata de viata prevazuta
≥ 30 Ani
Cable Max. Crush Resistance Installation (shortterm)
30000 N/m
Etanseitate
longitudinally watertight
Gama de temperatura - In instalare
-5 la +50 °C
Manta
LSOH-3, FRNC nach
IEC 61034-1/2, EN 50268-1/2
IEC 60754-1/2, EN 50267-1/2
IEC 60332-3-22 Cat.A
Temperatura maxima a mediului ambiant
60 °C
Cable Max. Crush Resistance Operation (longterm)
15000 N/m
Protectie la rozatoare
Yes, nonmetallic
Raza de curbura - Static
15 x Ø Ø
Mod-Camp / Diametru manta
50 ± 2,5 / 125 ± 1 µm
Potrivit
Cablu universal
Categorie
OM3 50/125µm
COD COMANDA
HSHAIBH083
PREG
5450
Multimode / singlemode
multimode
Fibra
50/125µ OM3 multimode
LxØ mm
1000x8
Numar fibre
8
Picaturi
d2
Accesorii optionale
HSELS083LG;HSELS083CG;HSELS083TG;Q7KB0416-S;Q7KB0416-B;Q7KB0416-R;Q7KB0416-Y;Q7KB0416-U
Unitate de ambalare
1 m.
Culoare
Negru
Manta
LSOH-3
Gama de temperatura - Transport/Depozitare
-25 to +70 °C
Gama de temperatura - Functionare
-25 la +60 °C
Cod de culori perechi
according to IEC 60304
Fabricant
Schrack
Raza de curbura - Dinamic
20 x Ø Ø
Aciditate
a1
PU
1
Masa neta
0,07 kg/m
Temperatura minima a mediului ambiant
-25 °C
Producere de fum
s2
Tensile strength
3500 N
Lungime / impachetare
tambur 2100m
Manta primara
250 ± 15 µm
Diametru
8 mm
Cupru / fibra optica
fibra optica
Euroclasa conform EN50575
Dca
| Lungime | 1000 mm |
| Diametru | 7.7 mm |
| Greutate | 0.07 kg |
